Coolant filtration unit
€1,654
Coolant filtration unit
\* Edit these rows under Content > Product page
Description
CONVENIENT EQUIPMENT FOR HANDLING ANTIFREEZE. DRAIN, CLEAN AND REFILL.
Compact unit for draining and refilling coolant. The tank holds 80 liters with a splash mat for an initial coarse filtration of the coolant when draining. Level pipe, 4 swivel wheels, one of which has a brake function. Refilling is done with a compressed air driven diaphragm pump, the liquid is filtered through a 100 micron steel filter that can be easily cleaned. Filling handle with 2.2 m. hose for refilling the cooling system from above or with the hose's quick coupling connected to the cooling system from below. The coupling is suitable for Volvo and Scania cooling systems.Price: 18.700 SEK
1 Wheels with brake function
2 Possibility of manual draining
3 Silencer
4 Drawbar stop position (adjustable)
5 Filter housing with steel filter, 100 micron
6 4 swivel castors
7 Filter/regulator/manometer
8 Splash mat for coarse filtration
Compressed air connection with needle valve for smooth pump speed adjustment mounted on the drawbar.
Level switch indicating overfill at approximately 75 liters.
Glycol is very difficult for the environment to degrade.
By reusing the liquid, we contribute to a better environment.
| Glycol cart | Diaphragm pump | Dead weight (TARA) empty | Noise | Filter for coolant | Working pressure |
|---|---|---|---|---|---|
80 L (overfill indication at about 75 L) | 20 L/min | 34 kg | <70dB(A) | 100 micron | 2,5 Bar |
